Basic Features
- Fast and accurate manual profiling
- Single screen overview with:
- Profile graph
- Key profile data (peak temperature)
- Oven settings & suggested improvements
- Intuitive user interface
- Solder paste specification library
- SPC and Cpk charting
- Profile stacking for up to 30 runs with data sharing
- Configurations: 7, 9, 12, and 24 TC
Technical Specifications
| Parameter | Value |
|---|---|
| Accuracy | ±0.5°C |
| Resolution | 0.1°C |
| Internal Operating Temp | 0°C to 85°C |
| Sample Rate | 0.002 to 50 per second |
| Data Points | 72K per channel |
| Temperature Range | -150°C to 1050°C |
| PC Connection | USB 2.0 (Std-A/Micro-B) |
| Power | Internal rechargeable NiMH battery, USB cable to PC or power supply, 10-min fast recharge for one profile |
| Wi-Fi | 2.4 GHz |
| ANT | 2.4 GHz |
| Thermocouple Compatibility | 7, 9, 12 Channel Units: Type K, Standard |
Dimensions (L x W x H mm)
- 7-Channel: 188.0 × 60.0 × 17.0
- 9-Channel: 188.0 × 75.0 × 17.0
- 12-Channel: 188.0 × 98.0 × 17.0
Additional
- Thermal Shields: Refer to tolerance table
- Vacuum Compatibility: 1.12kPa (8.40 torr) up to 45 minutes
