Technology Overview
Laser cutting focuses a high-power density beam to rapidly heat material to vaporization, forming precise micro-holes and continuous slits. Combined with CNC and CAD/CAM software, it enables unlimited contour cutting, flexible trajectory modification, multi-part processing, and automated 3D curve cutting for advanced stencil manufacturing.
Specifications
| Parameter Category | MF-680PRO | MF-6080 | MF-6120 |
|---|---|---|---|
| Cutting Speed | 15,000–30,000 pads/h | 20,000–50,000 pads/h | 20,000–50,000 pads/h |
| Cutting Area | 680 × 680 mm | 600 × 680 mm | 600 × 1200 mm |
| Cutting Thickness | ≤ 0.5 mm | ≤ 0.5 mm | ≤ 0.5 mm |
| Cutting Accuracy | ±0.005 mm | ±0.005 mm | ±0.005 mm |
| Repeatability | ±0.002 mm | ±0.002 mm | ±0.002 mm |
| Laser | IPG Fiber Laser | IPG Fiber Laser | IPG Fiber Laser |
| Laser Power | 100W / 200W | 100W / 200W | 100W / 200W |
| Operating Software | HY CUT | HY CUT | HY CUT |
| Data Format | STC / DXF / GBR / LMD | STC / DXF / GBR / LMD | STC / DXF / GBR / LMD |
| Machine Body | Marble | Marble | Marble |
| Machine Size (mm) | 1550 × 1400 × 1550 | 1580 × 1420 × 1550 | 2080 × 1500 × 1550 |
| Mesh Frame Size | 740 × 1500 × 40 (MAX) | 740 × 1500 × 40 (MAX) | 740 × 1500 × 40 (MAX) |
| Stencil Sheet Size | 760 × 760 (MAX) | 900 × 600 (MAX) | 1320 × 600 (MAX) |
| Machine Weight | 2400 Kg | 2200 Kg | 3200 Kg |
| Input Power | AC220V / 2KW | AC220V / 2KW | AC220V / 2KW |
| Auxiliary Gas | O₂ / N₂ / Compressed Air | O₂ / N₂ / Compressed Air | O₂ / N₂ / Compressed Air |
| Gas Pressure | 0.6 – 1.5 MPa | 0.6 – 1.5 MPa | 0.6 – 1.5 MPa |
| Temperature | 22 ± 2 ℃ | 22 ± 2 ℃ | 22 ± 2 ℃ |
| Humidity | ＜60% | ＜60% | ＜60% |
